Model Name | AMG-10IPPE01T2 |
Screen Size | 10.1" |
Active Display Area(mm) | 216.96(H)x135.6(V) |
Pixel Pitch(mm) | 0.1695(H)x0.1695(V) |
Display Mode | Normally Black |
Display Resolution(pixel) | 1280x800 |
Contrast Ratio | 262K |
Display Color | 1300:1 |
Brightness | 300nits |
Backlight | LED |
Viewing Angles(CR=10) | 160(H);160(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Touch Screen | PCAP Touch(10 points) |
Light Sensor | Optional |
Tempered glass | Optinal |
Signal Connector | HDMI |
Power Input | DC 12V |
Touch Controller | USB |
Dimension(VxHxT)mm | 261x174.2x25 |
Operating Temperature | -20~60℃(non-condensation) |
Storage Temperature | -30~70℃(non-condensation) |
Relative Humidity | 5~90(%RH) |
