Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for 24/7 continuous operation;
Durable mechanical design to meet tough environmental requirements;
Anti-glare tempered glass; Anti-dismantle Screw design;
Sunlight readable with high brightness up to 1000nits;
Customization service available;
Model No. | AMG-48PPC01N1 |
Device System | Andriod 4.0.4 |
Kernel Version | 2.6.34V2.0.0-166-g584fce8 |
HDMI port | 1 HDMI port |
USB 2.0 ports | Default 2xUSB 2.0 |
Ethernet ports | 1x10/100/1000BASE-T Gigabit Ethernet |
Audio | SPDF LINE |
Display Size | 48" |
Active Display Area(mm) | 1290.6x225.38 |
Max Resolution | 1920x357 |
Support Color | 16.7M |
Brightness(cd/m ) | 1000 |
Contrast Ratio | 3500:1 |
Aspect Ratio | 16:3 |
Viewing Angle(CR=10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 8ms |
Backlight | LED |
Input Rating | AC 90-264V 4A 47～63Hz |
Output Rating | 90W(max) |
Dimension(VxHxT) | 1337.1x276x78.4 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5[%RH]～90[%RH] |
