Branded LCD panels with perfect image quality and wide viewing angles;
Built with industrial-grade components for a reliable 24/7 long time operation;
Wide range operation temperature from -30~85℃; Light sensor for auto dimming
Passive Electromagnetic pen; Privacy film optional for security
Customization solution available
Model Name | AMG-15OPYH01T5 |
Screen Size | 15" |
Active Display Area(mm) | 304.128(H)x228.096(V) |
Pixel Pitch(mm) | 0.297(H)x0.297(V) |
Display Mode | Normally white |
Display Resolution(pixel) | 1024x768 |
Contrast Ratio | 700:1 |
Brightness | 450nits(Light Sensor) |
Backlight | LED |
Viewing Angles(CR=10) | 160(H);140(V) |
Response Time(Typ.Tr+Tf) | 8ms |
Touch Screen | PCAP Touch(10 points) |
Electromagnetic Pen | Passive |
Privacy Film | Support |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Touch Controller | USB |
Dimension(VxHxT) | 348.64x272.64x48.3 |
Operating Temperature | -30~85℃ |
Storage Temperature | -30~85℃ |
Relative Humidity | 5(%RH)~90(%RH) |
