Branded LCD panels with perfect image quality and wide viewing angles;
Built with industrial-grade components for a reliable 24/7 long time operation;
Wide range operation temperature from -30~85 ℃;
Various touchscreen options like PCAP, Resistive etc.
High-end mechanical design to meet tough environmental conditions and requirements,
Customization solution available
Model Name | AMG-10IPYY03T5 |
Screen Size | 10.4" |
Active Display Area (mm) | 211.2(H)x158.4(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally White |
Display Resolution (pixel) | 800x600 |
Contrast Ratio | 500:1 |
Display Color | PCT Touchscreen(10 Points) |
Brightness (CD/m ) | 230 |
Backlight | LED |
Viewing Angles (CR =10) | 120(H)x100(V) |
Response Time(Typ.Tr+Tf) | 35ms |
Signal Connector | VGA/DVI/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 260.4X193.4X38 |
Operating Temperature | -30~85℃ |
Storage Temperature | -30~85℃ |
Relative Humidity | 5(%RH)~90(%RH) |
