Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 continuous operation;
Durable mechanical design to meet tough environmental requirements;
5-Wire Resistive touchscreen for harsh operation environment;
Ingress Protection grade: IP67
Customization service available;
Model Name | AMG-06IPMI01T1 |
Screen Size | 6.5" |
Active Display Area (mm) | 132.48(H)x99.36(V) |
Pixel Pitch (mm) | 0.207(H)x0.207(V) |
Display Mode | Normally White |
Display Resolution (pixel) | 640x480 |
Contrast Ratio | 600:1 |
Brightness (cd/㎡) | 800 |
Backlight | LED |
Viewing Angles (CR =10) | 160Hx140V |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | WeiPu WY28-24(VGA) |
Power Consumption | DC 12V/24V |
Dimension(VxHxT) | 192x160x45 |
Ingress Protection | IP67 |
Operating Temperature | -30～80℃ |
Storage Temperature | -30～80℃ |
Relative Humidity | 5[%RH]～90[%RH] |
