Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 continuous operation;
Durable mechanical design to meet tough environmental requirements;
PCAP touchscreen ; Optical bonding technology; Anti-glare glass;
IP65 waterproof; High brightness with light sensor for auto dimming
Customization service available;
Model Name | AMG-10IPHJ01T1 |
Screen Size | 10.4" |
Active Display Area(mm) | 211.2(H)x158.4(V) |
Pixel Pitch(mm) | 0.264(H)x0.264(V) |
Display Mode | Normally white |
Display Color | 16.2M/262K |
Display Resolution(pixel) | 800x600 |
Contrast Ratio | 500:1 |
Brightness | 1000nits(Light Sensor) |
Backlight | LED |
Viewing Angles(CR=10) | 160(H);130(V) |
Response Time(Typ.Tr+Tf) | 35ms |
Touch Screen | PCAP Touch(10 points) |
Light Sensor | Support |
Optical Bonding | Support |
Signal Connector | VGA/DVI-D |
Power Consumption | DC 12V |
Touch Controller | USB |
Dimension(VxHxT)mm | 295x205x40 |
Operating Temperature | -20～70℃ |
Storage Temperature | -20～70℃ |
Relative Humidity | 5[%RH]～90[%RH] |
