Branded LCD panels with perfect image quality and wide viewing angles;
Built with industrial-grade components for a reliable 24/7 continuously operation;
10-points PCAP touchscreen; LED backlight, brightness up to 800 nits;
Full flat surface design for IP65 waterproof, dust proof environments;
Customization solution available;
Model Name | AMG-18IPTL01T1 |
Screen Size | 18.5" |
Active Display Area (mm) | 409.8(H)x230.4(V) |
Pixel Pitch (mm) | 0.3(H)x0.3(V) |
Display Mode | Normally White |
Display Resolution (pixel) | 1366x768 |
Contrast Ratio | 1000:1 |
Touch screen(optional) | PCAP Touch(10 Points) |
Brightness (CD/m ) | 800 |
Backlight | LED |
Viewing Angles (CR =10) | 170Hx160V |
Response Time(Typ.Tr+Tf) | 5ms |
Signal Connector | VGA/DVI/USB |
Power Consumption | DC 24V |
Dimension(VxHxT) | 480x308x57.8 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
