The high brightness LCD monitor AMG-22IPPC01T6 offered by Amongo is built with the following benefits:
Branded LCD panels with perfect image quality and wide viewing angles;
Built with industrial-grade components for a reliable 24/7 continuously operation;
LED backlight, brightness up to1000 nits, light sensor optional for auto-dimming;
PCAP touchscreen with Aluminum bezel for IP65 waterproof, dustproof etc.
Customization solution available;
Model Name | AMG-22IPPC01T6 |
Screen Size | 22" |
Active Display Area (mm) | 473.76(H)x296.1(V) |
Pixel Pitch (mm) | 0.282(H)x0.282(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 16.7M |
Contrast Ratio | 1680x1050 |
Display Color | 1000:1 |
Brightness (CD/㎡) | 1000nits |
Backlight | LED |
Viewing Angles (CR =10) | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 573.7x400.1x60.8 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
