Branded LCD panels with perfect image quality and wide viewing angles;
Built with industrial-grade components for a reliable 24/7 continuously operation;
10-points PCAP touchscreen; LED backlight, brightness up to 1200 nits;
With light sensor for auto-dimming, to save energy and extend backlight life span;
Aluminum front bezel for IP65 waterproof, dust proof environments;
Customization solution available;
Model Name | AMG-17IPPC02T3 |
Screen Size | 17" |
Active Display Area (mm) | 337.920(H)x270.336(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally White |
Display Resolution (pixel) | 1280X1024 |
Contrast Ratio | 1000:1 |
Display Color | 16.7M color |
Brightness (CD/㎡) | Max:1200(Light Sensor) |
Backlight | CCFL/LED |
Viewing Angles (CR =10) | 170Hx160V |
Response Time(Typ.Tr+Tf) | 5ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 440.6X354.6X56.7 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
Touch Screen | PCAP Touch(10 points) |
