Full flat surface, PCAP multi-touchscreen
IP65 waterproof mold frame
Surface dust-proof, vandal-proof
Application:
Kiosk / Medical self-service / Digital signage etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-21OPJH01T1 |
| Screen Size | 21" |
| Active Display Area(mm) | 476.64 (H) x 268.11 (V) |
| Pixel Pitch(mm) | 0.248 (H) × 0.248(V) |
| Display Mode | Normally Black |
| Display Resolution(pixel) | 1920x1080 |
| Contrast Ratio | 3000:01:00 |
| Brightness | 250nits |
| Backlight | LED |
| Viewing Angles(CR=10) | 178(H);178(V) |
| Response Time(Typ.Tr+Tf) | 18ms |
| Optional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Optional |
| I/O Interface | |
| Signal Connector | VGA/DP/ HDMI/Audio |
| Power Consumption | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 519.6*316.2*43.3 |
| Environmental | |
| Operating Temperature | 0~50℃(non-condensation) |
| Storage Temperature | -20~60℃(non-condensation) |
| Relative Humidity | 5~90(%RH) |
