Branded LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7/365 operation
LED backlight for low power consumption to save more energy
Sunlight readable with brightness up to 1500 nits;
High-end mechanical design to meet tough environmental conditions and requirements,
Customization solution available
Model Name | AMG-10OPDR05N1 |
Screen Size | 10.4" |
Active Display Area (mm) | 211.2(H)x158.4(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally Black |
Display Resolution (pixel) | 800x600 |
Contrast Ratio | 500:1 |
Display Color | 16.2M/262K |
Brightness (CD/m ) | 1500 |
Backlight | LED |
Viewing Angles (CR =10) | 100(H)x120(V) |
Response Time(Typ.Tr+Tf) | 35ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 204x210x48 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
