Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 continuous operation;
Durable mechanical design to meet tough environmental requirements;
Touchscreen optional as required; built with motion sensor, HD camera;
Ingress Protection grade: IP65;
Customization service available;
Model Name | AMG-07IPLV01T1 |
Screen Size | 7" |
Active Display Area(mm) | 153.6(H)x90(V) |
Pixel Pitch(mm) | 0.150(H)x0.150(V) |
Display Mode | Normally white |
Display Color | 16.2M |
Display Resolution(pixel) | 1024x600 |
Contrast Ratio | 700:1 |
Brightness | 600nits |
Backlight | LED |
Viewing Angles(CR=10) | 160(H);130(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Touch Screen | Optional |
Camera | Support |
Motion Sensor | Support |
Signal Connector | VGA/DVI-D/HDMI/Audio |
Power Consumption | DC 12V |
Dimension(VxHxT)mm | 212x180x63 |
Operating Temperature | -20～60℃ |
Storage Temperature | -30～70℃ |
Relative Humidity | 5[%RH]～90[%RH] |
