Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Durable mechanical design to meet tough environmental requirements;
Full flat surface design, for easy installation and maintenance;
Front IP65 water proof, vandal proof, dust proof;
Support HD camera for IoT application;
Customization service available;
Model Name | AMG-21PPC01TA |
CPU | RK3368 Eight Core ARM-A53 1.5GHz |
RAM | 2GB(4GB optional) |
ROM | 8GB(16/32GB optional) |
OS | Android 5.1.1 |
RS232 Port | 1 x RS232 |
HDMI | 1 x HDMI |
USB Ports | 3 x USB |
SD Card | Support |
Ethernet | 4G/3G, Ethernet, WiFi, GPS, Bluetooth optional |
Screen Size | 21.5" |
Active Area(mm) | 476.64(H)x268.11(V) |
Pixel Pitch(mm) | 0.24825(H)x0.24825(V) |
Display Resolution | 1920x1080 |
Display Color | Normally Black |
Brightness(cd/㎡) | 250nits |
Contrast Ratio | 3000:1 |
Backlight | LED |
Viewing Angles | 178(H);178(V) |
Response Time(Tr+Tf) | 18ms |
Touch Screen | PCAP Touch(10 points) |
Camera | Support |
Dimension(VxHxT)mm | 518x353.9x53 |
Operating Temperature | -30~85℃(non-condensation) |
Storage Temperature | -30~85℃(non-condensation) |
Relative Humidity | 5~90(%RH) |
