Branded LCD panels with perfect image quality and wide viewing angles ;
Built with industrial-grade components for a reliable 24/7 long time working;
LED backlight for low power consumption to save more energy;
Various touchscreen options like PCAP, Resistive etc.;
Sunlight readable with brightness up to 550 nits;
Customization solution available;
Model Name | AMG-55PPCxxxx |
CPU | Freescale Cortex A9 i.MX 6 |
Memory | On board 1GB DDR3 Memory 800MHz |
Flash | On board iNAND 4GB |
Play Mode | Music/Picture/Video/Water Subtitles |
OS | Android |
CF port | 1x CF port |
SD port | 1x SD port |
MMC port | 1x MMC port |
USB 2.0 port | Default x 1 USB |
Audio | Dual Track/Stereo |
Video Playback System | PAL/NTSC |
Ethernet ports | 1x 10/100/1000Mbps Ethernet LAN |
Display Size | 55" |
Active Display Area(mm) | 1209(H)×680(V) |
Max Resolution | 1920x1080 |
Support Color | 16.7M |
Luminance(CD/M2) | 550 |
Contrast Ratio | 1500:1 |
Pixel Pitch (mm) | 0.63x0.63 |
Viewing Angle | 178(H);178(V) |
Dimension(VxHxT) | 1377.6x838.4x68.9 |
Input Voltage | AC 100～240 |
Ouput Rating | 100W(Max) |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5[%RH]～90[%RH] |
