Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7 long timer operation;
Touchscreen is optional such as PCAP, Resistive etc
Robust mechanical design with Aluminum for metal IP65/NEMA 4 front panel to meet tough environmental conditions and requirements;
Easy-to-install with rack mounting enclosures.
Customization service available
Model Name | AMG-10IPZL01T1 |
Screen Size | 10.4" |
Active Display Area (mm) | 211.2(H)x158.4(V) |
Pixel Pitch (mm) | 0.20625(H)x0.20625(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 262K/16.7M |
Contrast Ratio | 1024x768 |
Display Color | 900:1 |
Brightness (CD/㎡) | 1000nits(Light Sensor) |
Backlight | LED |
Viewing Angles (CR =10) | 150(H);150(V |
Response Time(Typ.Tr+Tf) | 16ms |
Signal Connector | VGA/DVI/USB |
Power Consumption | DC 12V 4A |
Dimension(VxHxT) | 242.6x188.6x45.8 |
Operating Temperature | -20～70℃ |
Storage Temperature | -30～80℃ |
Relative Humidity | 5(%RH)～90(%RH) |
