Branded LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7 long time operation
Touchscreen can be optional from PCAP, Resistive etc
Easy-to-install in a desktop holder with VESA holes backside
Good choice for application for console or control center
Model Name | AMG-10IPZY01N1 |
Screen Size | 10.4" |
Active Display Area (mm) | 212.7(H)x159.4(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 800X600 |
Contrast Ratio | 800:1 |
Display Color | 16.7M/262K |
Brightness (cd/㎡) | 300 |
Backlight | LED |
Viewing Angles (CR =10) | 130(H)x140(V) |
Response Time(Typ.Tr+Tf) | 30ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 248X195X34.5 |
Operating Temperature | -20～70℃ |
Storage Temperature | -30～80℃ |
Model Name | 5(%RH)～90(%RH) |
