Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
High-end mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-11IPPC01T1 |
Screen Size | 11.6" |
Active Display Area (mm) | 270.37(H)x159.79(V) |
Pixel Pitch (mm) | 0.13455(H)x0.13455(V) |
Display Mode | Normally black |
Display Resolution (pixel) | 16.7M |
Contrast Ratio | 1920x1080 |
Display Color | 1000:1 |
Brightness (CD/㎡) | 300nits |
Backlight | LED |
Viewing Angles (CR =10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 337x225x45 |
Operating Temperature | 0～50℃ |
Storage Temperature | -10～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
Touch Screen | PCAP Touch(10 points) |
