AMG-12OPHA01T1
800x600 pixels
Brightness:400 nits
Capacitive Touch
For: ATM/Kiosk
Branded LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7/365 operation
LED backlight for low power consumption to save more energy
Various touchscreen options like PCAP, Resistive, IR, SAW etc
High-end mechanical design to meet tough environmental conditions and requirements
Rear mounted or VESA mounted design for easy installation for kiosks application
Customization service is available
Model Name | AMG-12OPMD01N1 |
Screen Size | 12.1" |
Active Display Area (mm) | 246.0 (H) x 184.5 (V) |
Pixel Pitch (mm) | 0.3075(H) x 0.3075(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 800x600 |
Contrast Ratio | 500:1 |
Display Color | 262k,144 colors |
Brightness (CD/㎡) | 400 |
Backlight | LED |
Viewing Angles (CR =10) | 140 (H); 110 (V) |
Response Time(Typ.Tr+Tf) | 35ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 300x248x34 |
Operating Temperature | -10～65℃ |
Storage Temperature | -30～70℃ |
Relative Humidity | 5(%RH)～90(%RH) |
