Model Name | AMG-12PPC01T1 |
CPU | Intel Atom N270 (1.6GHz)CPU |
CHIPSET | Intel 945GSE+ICH7 |
Memory | 2GB DDR II SDRAM |
HDD | 2.5" 320G HDD |
PS/2 port | NA |
VGA port | 1 x VGA port |
COM ports | 1x RS232 port |
USB 2.0 ports | 3 x USB2.0 |
Ethernet ports | 1x Gigabit LAN |
Audio | Line-out/Optical SPDIF_out connector |
Display Type/ Size(Diagonal) | 12.1" |
Active Display Area(mm) | 246(H)x184.5(V) |
Max Resolution | 800x600 |
Display Color | 16.2M/262K |
Luminance(cd/m ) | 400 |
Contrast Ratio | 700:1 |
Pixel Pitch (mm) | 0.3075x0.3075 |
Viewing Angle | Normally White |
Display Mode | 110(H);140(V) |
Response Time(Typ.Tr+Tf) | 35ms |
Dimension(VxHxT) | 379x284x78 |
Type | Resistive Touchscreen |
Use connector | 4pin USB2.0 |
Input Voltage | AC 100-240V 4A 47～63Hz |
Output Rating | 72W(max) |
Output Voltage | +12V @6A; |
Operating Temperature | -30～80℃ |
Storage Temperature | -30～80℃ |
Relative Humidity | 5[%RH]～90[%RH] |
