Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
Durable mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-12IPTP01T1 |
Screen Size | 12.1" |
Active Display Area (mm) | 245.76(H) x 184.32(V) |
Pixel Pitch (mm) | 0.24(H)x0.24(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 1024x768 |
Contrast Ratio | 700:1 |
Display Color | 16.2M/262K |
Brightness (CD/㎡) | 500 |
Backlight | LED |
Viewing Angles (CR =10) | 160(H)X160(V) |
Response Time(Typ.Tr+Tf) | 35ms |
Signal Connector | VGA/DVI/DC2.0 |
Power Consumption | DC 12V |
Dimension(VxHxT) | 300X240X49 |
Operating Temperature | -30～80℃ |
Storage Temperature | -30～80℃ |
Relative Humidity | 5(%RH)～90(%RH) |
