The 13.3 inch industrial all in one computer AMG-13PPC01T2 customized by Amongo is widely installed in different applications with the following features:
High quality LCD panels with perfect image effect and wide view angles;
Latest Android OS, supporting Ethernet / Wi-Fi / Bluetooth / 4G network;
Full flat surface design to support front IP65 waterproof, dust proof and vandal proof with tempered glass;
Stable quality, high reliability to ensure the long time operation during bad environment;
Suitable solutions for all the projects related with AI and IoT ;
System | Model Name | AMG-13PPC01T2 |
CPU | RK3399 Dual Cortex A72+Quad core A53 64bit CPU | |
RAM | 2GB(4GB Optional) | |
ROM | 16GB( 8 / 32 / 64GB Optional) | |
OS | Android 7.1 | |
USB ports | 2 x USB 3.0 | |
LAN | 4G/3G, 2 x Ethernet, WiFi, GPS Support | |
SD Card | Support | |
LED ports | 2 x LED | |
Speaker port | 1 x Speaker | |
Tel port | 1 x Telephone | |
LCD | Screen Size | 13.3" |
Active Area(mm) | 293.76(H)x165.24(V) | |
Pixel Pitch(mm) | 0.153(H)x0.153(V) | |
Display Resolution | 1920x1080 | |
Display Color | Normally Black | |
Brightness | 220nits | |
Contrast Ratio | 600:1 | |
Viewing Angles | 160(H);160(V) | |
Response Time(Tr+Tf) | 30ms | |
Backlight | LED | |
Optional | Touch Screen | PCAP Touch(10 points) |
Tempered Glass | Optional | |
Light Sensor | Optional | |
Mechanical | Dimension(VxHxT)mm | 334.2x216.4x50 |
Environmental | Operating Temperature | 0~50℃(non-condensation) |
Storage Temperature | -20~60℃(non-condensation) | |
Relative Humidity | 5~90(%RH) |
