Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
Durable mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-15IPAL01T1 |
Screen Size | 15.6" |
Active Display Area(mm) | 344.16(H)x193.59(V) |
Pixel Pitch(mm) | 0.17925(H)x0.17925(V) |
Display Mode | Normally black |
Display Color | 262K |
Display Resolution(pixel) | 1920x1080 |
Contrast Ratio | 800:1 |
Brightness | 300nits |
Backlight | LED |
Viewing Angles(CR=10) | 170(H);170(V) |
Response Time(Typ.Tr+Tf) | 30ms |
Touch Screen | Resistive touch(5 wire) |
Brightenss / Light Sensor | Optional |
Signal Connector | VGA/DVI-D |
Power Input | DC 12V (DC2.0/DC2.5) |
Touch Controller | USB |
Dimension(VxHxT) | 397.5x246.8x35 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
