Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 longtime use;
Durable mechanical design to meet tough environmental conditions and requirements;
Side frame with flange design for easy installation and maintenance;
Molded side frame integrated with touchscreen for front IP65 waterproof;
Customization service available;
Model Name | AMG-17OPGD01T3 |
Screen Size | 17" |
Active Display Area (mm) | 337.920(H)x270.336(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 1280x1024 |
Contrast Ratio | 1000:1 |
Display Color | 16.7M |
Brightness (CD/㎡) | 250/300/350nits |
Backlight | LED |
Viewing Angles (CR =10) | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 5ms |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 391x323.4x59.2 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
Touch Screen | PCAP Touch(10 points) |
