Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
Durable mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
With light sensor for auto dimming brightness and save energy
Customization service available
Model Name | AMG-17IPZL01T1 |
Screen Size | 17" |
Active Display Area(mm) | 337.920(H)x270.336(V) |
Pixel Pitch(mm) | 0.264(H)x0.264(V) |
Display Mode | Normally white |
Display Color | 16.7M |
Display Resolution(pixel) | 1280x1024 |
Contrast Ratio | 1000:1 |
Brightness | 350nits(Light Sensor) |
Backlight | LED |
Viewing Angles(CR=10) | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 5ms |
Touch Screen | IR Touchscreen |
Light Sensor | Support |
Signal Connector | VGA/DVI-D |
Power Input | DC 12V |
Touch Controller | USB |
Dimension(VxHxT) | 388.4x356.2x52.6 |
Operating Temperature | -30～85℃ |
Storage Temperature | -30～85℃ |
Relative Humidity | 5(%RH)～90(%RH) |
