Model Name | AMG-19PPC02T5 |
CPU | Intel ® Bay Trail J1900 Mini-ITX(2GHz) |
Memory | DDR3L 1333/1600MHz 2GB |
HDD | 60GB (optional) |
COM ports | 1 x COM port |
PS/2 port | NA |
VGA port | 1 x VGA port |
HDMI port | 1 x HDMI port |
USB ports | Default 2 x USB 2.0 |
Ethernet ports | 1x10/100/1000BASE-T Gigabit Ethernet |
Audio | Line-out,Mic-in |
Display Size(Diagonal) | 19" |
Active Display Area(mm) | 376.32(H)x301.06(V) |
Max Resolution | 1280x1024 |
Support Color | 16.7M |
Brightness(CD/㎡) | 250 |
Contrast Ratio | 1000:1 |
Pixel Pitch(mm) | 0.264(H)x0.264(V) |
Viewing Angle | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 5ms |
Backlight | LED |
Type | Resistive Touchscreen |
Use connector | 4pin USB2.0 |
Input Voltage | AC 90-264V 4A 47～63Hz |
Output Rating | 60W(max) |
Ouput Voltage | +12V @5A; |
Dimension(VxHxT) | 474.6x399.6x90.36 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5[%RH]～90[%RH] |
