Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
Durable mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
High cost effective solution to replace ELO touch monitor
Customization service available
Model Name | AMG-19OPKJ01T1 |
Screen Size | 19" |
Active Display Area(mm) | 376.32(H)x301.06(V) |
Pixel Pitch(mm) | 0.294(H)x0.294(V) |
Display Mode | Normally white |
Display Resolution(pixel) | 1280x1024 |
Contrast Ratio | 1000:1 |
Brightness | 350nits |
Backlight | LED |
Viewing Angles(CR=10) | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 5ms |
Touch Screen | PCAP Touch(10 points) |
Electromagnetic Pen | Optional |
Privacy Film | Optional |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Touch Controller | USB |
Dimension(VxHxT) | 415x343x50 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
