Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
High-end mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-22IPPC01T4 |
Screen Size | 21.5" |
Active Display Area (mm) | 473.76(H)x296.1(V) |
Pixel Pitch (mm) | 0.282(H)x0.282(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 1680X1050 |
Contrast Ratio | 1000:1 |
Display Color | 16.7M color |
Brightness (CD/㎡) | 300 |
Backlight | LED |
Viewing Angles (CR =10) | 178Hx178V |
Response Time(Typ.Tr+Tf) | 8ms |
Signal Connector | VGA/DVI |
Power Consumption | DC2.0 |
Dimension(VxHxT) | 573.7X400.1X66.9 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
Touch Screen | IR Touch |
