Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7 long time operation;
Touchscreen is optional such as PCAP, Resistive etc
Robust mechanical design with Aluminum for metal IP65/NEMA 4 front panel to meet tough environmental conditions and requirements;
Easy-to-install with rack mounting enclosures.
Customization service available
Model Name | AMG-21OPSL01T1 |
Screen Size | 21.5" |
Active Display Area(mm) | 476.064(H)x267.786(V) |
Pixel Pitch(mm) | 0.24795(H)x0.24795(V) |
Display Mode | Normally Black |
Display Resolution(pixel) | 1920x1080 |
Contrast Ratio | 3000:1 |
Brightness | 250nits |
Backlight | LED |
Viewing Angles(CR=10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 18ms |
Touch Screen | PCAP Touch(10 points) |
Anti-glare | Optional |
Privacy Film | Optional |
Signal Connector | VGA/DVI-D/HDMI/Audio |
Power Input | DC 12V |
Touch Controller | USB |
Dimension(VxHxT) | 543.9x303.4x43 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
