Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
High-end mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
High brightness over 1000nits, sunlight readable
Customization service available
Model Name | AMG-22IPPC01T6 |
Screen Size | 22" |
Active Display Area (mm) | 473.76(H)x296.1(V) |
Pixel Pitch (mm) | 0.282(H)x0.282(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 16.7M |
Contrast Ratio | 1680x1050 |
Display Color | 1000:1 |
Brightness (CD/㎡) | 1000nits |
Backlight | LED |
Viewing Angles (CR =10) | 170(H);160(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 573.7x400.1x60.8 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
