AMG-24OPHA01N1
1920x1080 pixels
Brightness:250 nits
No Touch
For: ATM/Kiosk
Branded 24 inch widescreen LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7/365 operation
LED backlight for low power consumption to save more energy
Various touchscreen options like PCAP, Resistive, IR, SAW etc
High-end mechanical design to meet tough environmental conditions and requirements
Customization service as required
Model Name | AMG-24OPHA01N1 |
Screen Size | 24" |
Active Display Area (mm) | 531.36 (H) x 298.89(V) |
Pixel Pitch (mm) | 0.27675(H) x 0.27675 (V) |
Display Mode | Normally Black |
Display Resolution (pixel) | 1920x1080 |
Contrast Ratio | 3000:1 |
Display Color | 16.7M |
Brightness (CD/㎡) | 250 |
Backlight | LED |
Viewing Angles (CR =10) | 178 (H); 178 (V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI/HDMI/Audio |
Power Consumption | DC 12V |
Dimension(VxHxT) | 559x326.2x46 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
Touch Screen(Optional) | Optional |
