Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
High-end mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-32IPPC05T2 |
Screen Size | 31.5" |
Active Display Area (mm) | 679.92(H)x392.58(V) |
Pixel Pitch (mm) | 0.18175(H)x0.18175(V) |
Display Mode | Normally Black |
Display Resolution (pixel) | 1920X1080 |
Contrast Ratio | 4000:1 |
Display Color | Multi Touch(2 Points)/IR Touch |
Brightness (CD/㎡) | 450 |
Backlight | LED |
Viewing Angles (CR =10) | 176Hx176V |
Response Time(Typ.Tr+Tf) | 8.5ms |
Signal Connector | VGA/DVI/AV/HDMI/USB |
Power Consumption | AC 110-230V |
Dimension(VxHxT) | 780.8X470.4X74.0 |
Operating Temperature | 0～50℃ |
Storage Temperature | -10～70℃ |
Relative Humidity | 5(%RH)～90(%RH) |
