Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Touchscreen is optional such as PCAP, Resistive etc
Robust mechanical design with Aluminum for metal IP65/NEMA 4 front panel to meet tough environmental conditions and requirements;
Easy-to-install with rack mounting enclosures.
Customization service available
Model Name | AMG-06OPSK01N1 |
Screen Size | 5.7" |
Active Display Area (mm) | 115.2(H) x 86.4(V) |
Pixel Pitch (mm) | 0.18x0.18 |
Display Mode | Normally white |
Display Resolution (pixel) | 640x480 |
Contrast Ratio | 800:1 |
Display Color | 262K |
Brightness (CD/㎡) | 700 |
Backlight | LED |
Viewing Angles (CR =10) | 160(H)X140(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA |
Power Consumption | DC 12V |
Dimension(VxHxT) | 188X114X36.3 |
Operating Temperature | -30～80℃ |
Storage Temperature | -30～80℃ |
Relative Humidity | 5(%RH)～90(%RH) |
