Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies including PCAP, Resistive, IR etc
High-end mechanical design to meet tough environmental conditions and requirements;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available
Model Name | AMG-07IPPC01T1 |
Screen Size | 7" |
Active Display Area (mm) | 152.4 (H) x91.44 (V) |
Pixel Pitch (mm) | 0.1905 (H) x 0.1905 (V) |
Display Mode | Normally white |
Display Resolution (pixel) | 800x480 |
Contrast Ratio | 500:1 |
Display Color | 16.2M/262K colors |
Brightness (CD/㎡) | 350 |
Backlight | LED |
Viewing Angles (CR =10) | 110(H)x130 (V) |
Response Time(Typ.Tr+Tf) | 30ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 234.6x173.4x47.8 |
Operating Temperature | -20～70℃ |
Storage Temperature | -20～70℃ |
Relative Humidity | 5(%RH)～90(%RH) |
