Model Name | AMG-07PPC01T1 |
CPU | Intel ® Bay Trail-M N2930 SOC Processor 1.83G |
Memory | DDR3L 1333MHz 4GB |
HDD | Msata 32G |
DVI port | 1xDVI port |
COM ports | 4xCOM (optional) |
USB ports | 3xUSB2.0 (1xUSB 3.0) |
Ethernet ports | 2xRTL8111G PCI-E Gigabit LAN |
Audio | 1xLine-out port |
Display Size | 7" |
Active Display Area(mm) | 152.40(H)x91.44(V) |
Max Resolution | 800x480 |
Support Color | 16.2M/262K colors |
Luminance(CD/㎡) | 350 |
Contrast Ratio | 500:1 |
Pixel Pitch (mm) | 0.1907(H)x0.1907(V) |
Display Mode | Normally White |
Viewing Angle | 110(H);130(V) |
Backlight | LED |
Type | Resistive Touchscreen |
Use connector | 4pin USB2.0 |
Input Voltage | DC 9-24V IN |
Output Rating | 20W(max) |
Dimension(VxHxT) | 234.4x173.4x48 |
Operating Temperature | -20～70℃ |
Storage Temperature | -20～70℃ |
Relative Humidity | 5[%RH]～90[%RH] |
