PCAP Multi-touch screen
Support embedded / VESA installation
Full flat surface design
High brightness,Light Sensor
High reliability and long lifetime
Application:
AFC/ Non-cash equipment / Kiosk etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-08OPBK01T1 |
| Screen Size | 8" |
| Active Display Area(mm) | 162.05(H)x121.54(V) |
| Pixel Pitch(mm) | 0.15825(H)x0.05275(V) |
| Display Mode | Normally Black |
| Display Resolution(pixel) | 1024x768 |
| Contrast Ratio | 800:1 |
| Display Color | 16.7M |
| Brightness | 1000nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 170(H);170(V) |
| Response Time（Typ.Tr+Tf） | 25ms |
| Optional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Support |
| Tempered glass | Optional |
| I/O Interface | |
| Signal Connector | HDMI |
| Power Input | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 60*18.5*41.5 |
| Environmental | |
| Operating Temperature | 0~50℃（non-condensation） |
| Storage Temperature | -20~60°C（non-condesation） |
| Relative Humidity | 5~90(% RH) |
