Convex full flat fillet design
PCAP multi-touchscreen(10 points)
Surface IP65 Waterproof, Dust-proof
Surface hardness MoHs 7, scratch resistant
High brightness / light sensor
Starting at low temperature, stable quality
Application:
Kiosk/Industrial automation etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-10IPYZR1T1 |
| Screen Size | 10.4" |
| Active Display Area(mm) | 211.2(H)×158.4(V) |
| Pixel Pitch(mm) | 0.20625(H)×0.20625(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1024x768 |
| Contrast Ratio | 900:01:00 |
| Brightness | 1000nits |
| Backlight | LED |
| Viewing Angles(CR=10) | 150(H);150(V) |
| Response Time(Typ.Tr+Tf) | 16ms |
| Opitional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Support |
| Privacy Film | Optional |
| I/O Interface | |
| Signal Connector | DP/HDMILVDS |
| Power Input | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 248.8X199.6X36.9 |
| Environmental | |
| Operating Temperature | -20~70℃(not clotted) |
| Storage Temperature | -30~80℃(not clotted) |
| Relative Humidity | 5~90(%RH) |
