PCAP Multi-touch screen
High brihtness/sunlight readable
Light senor/energy saving
IP65 waterproof,vandal-proof,dust-proof
Full-surface scratch-resistant design,MoHs 7
Application:
Semi-outdoor Kiosk/AFC/Industrial automation etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-21IPRV01T1 |
| Screen Size | 21.5" |
| Active Display Area(mm) | 476.64(H)x268.11(V) |
| Pixel Pitch(mm) | 0.3(H)x0.3(V) |
| Display Mode | Normally Black |
| Display Resolution(pixel) | 1920x1080 |
| Contrast Ratio | 3000:1 |
| Display Color | 16.7M |
| Brightness | 1000nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 178(H);178(V) |
| Response Time（Typ.Tr+Tf） | 18ms |
| Optional | |
| Touch Screen | PCAP Touch（10 points） |
| Light Sensor | Optional |
| Tempered glass | Supprot |
| I/O Interface | |
| Signal Connector | HDMI |
| Power Consumption | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 518*313.9*45.5 |
| Environmental | |
| Operating Temperature | 0~50℃（non-condensation） |
| Storage Temperature | -20~60℃（non-condesation） |
| Relative Humidity | 5~90(% RH) |
