PCAP Multi-touch screen
High Brightness/Sunlightn readable
Aluminum panel design，rugged case
Great heat dissipation
High Reliability and long lifetime
Application:
AFC/ Non-cash equipment / Kiosk etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-22IPPC01T6 |
| Screen Size | 22" |
| Active Display Area(mm) | 473.76(H)x296.1(V) |
| Pixel Pitch(mm) | 0.282(H)x0.282(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1680x1050 |
| Contrast Ratio | 1000:1 |
| Display Color | 16.7M |
| Brightness | 1000nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 170(H);160(V) |
| Response Time（Typ.Tr+Tf） | 25ms |
| Optional | |
| Touch Screen | PCAP Touch（10 points） |
| Light Sensor | Optional |
| I/O Interface | |
| Signal Connector | VGA/DVI/DC2.5 |
| Power Consumption | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 573.7*400.1*60.8 |
| Environmental | |
| Operating Temperature | 0~50℃（non-condensation） |
| Storage Temperature | -20~60℃（non-condesation） |
| Relative Humidity | 5~90(% RH) |
