Model | AMG-B886 |
CPU | Intel® Atom™ Cedar Trail processor N2600 / 2800 |
FSB | 800 / 1066MHz |
Chipset | CG82NM10 |
BIOS | System BIOS: SPI BIOS |
Architecture | DDR3L-800MT/s and 1066MT/s |
Capacity | Onboard 2GB |
Graphic Controller | Intel®3600 series graphic media accelerator |
LCD/DVI/LVDS | N/A |
HDMI | Support HDMI 1.3, type A, 19pin |
Max. Resolution: 2560 * 1600 | |
VGA | 1*DB15 |
Max. Resolution: 1920 * 1200 | |
Dual Display | VGA+HDMI |
Controller | LAN 1: Intel 82583 GbE Lan |
LAN 2: N/A | |
Realtek HD ALC662 audio decoder(LINEOUT+ Mic ) | |
WINBOND 83627DHG | |
Watch Dog Timer | Timer 1 - 255 sec./min., support system reset |
Smart Fan | Fan-less |
USB | 6* USB 2.0/1.1 compatible |
Serial Port | 1* RS232 |
Mini-PCIe | 1* Mini-PCIe socket, support WIFI/3G wireless network |
UIM Socket | 1* standard SIM card socket |
SATA | 1* SATAII |
Power Type | Wide range voltage input: DC12-24V |
Power Consumption | Typical power: 12W |
Operating Environment | -20°C ~ 60°C |
Storage Environment | -40°C ~ 85°C |
Operating Humidity | 10% ~ 90% relative humidity, non-condensing |
Storage Humidity | 10% ~ 90% relative humidity, non-condensing |
Dimensions | 145mm * 135mm * 32mm (L*W*H) |
Weight | 1.28Kg |
Regulatory Compliance | FCC, CE, RoHS compliant |
